Application
Almost all types of liquid or paste products that can be packed in a pouch can be filled on a FlexiMach SUP machine: food and beverages, animal feeds/pet food, detergents, cosmetics, chemical products, etc.
Main Feature
1.FM-300/500 SUP Series include Simplex-Duplex-Triplex-Quadro Version
2.Packing speed could be 30 to 120ppm due to different version
3.Total wash down design, waterproof grade.
4.Can work in extreme condition.
5.Optional:On-line weighing and auto correction of filling weight.
6.The entire machine is all made up of 304 stainless steel
7.Branded OutSourcing components
8.User Friendly and Easy Maintenance
Specification
Model | FM-300 | FM-500 |
Filling range | 100-300 ml | 100-500ML |
Pouch width | 80 - 100 mm | 80 - 140 mm |
Pouch height | 100 - 230 mm | 100 - 300 mm |
Pouch gusset | 30 - 50 mm | 30 - 90 mm |
Pouch Shape | Stand up pouch |
Version | Speed(ppm) |
Simplex | 30-40 | 20-40 |
Duplex | 60-70 | 40-70 |
Triplex | 90-100 | 80-90 |
Quadro | 110-120 | 90-100 |
Pouch Styles
stand up pouches with spout, ZIP, valve,hand-held hole
Option
Filling :1.Flow meter for liquid 2.Servo piston pump for vicious paste
SEMI AUTOMATIC CIP SYSTEM
Video Link
Youtube: https://www.youtube.com/watch?v=kDGh0KuQ9-Q
